AF-B Box filling & sealing packaging machine

Brief Introduce:

AF-B series coffee capsule packaging machine is the solution to pack Nespresso/Dolce Gusto/ K cups/Lavazza capsules into one box.

This is a fully automatic line with incorporates a variety of sensors that allow it to detect and smartly decide how to respond to the presence or absence of cups, lboxes, position, etc.

Special designed conveying system, extremely smooth operation at all speeds.

This machine can produce both Plastic and Aluminum Nespresso capsules

Features
  1. PLC automatic control, Can adjust the speed, Save labor
  2. Can use for different sizes of boxes within a certain range
  3. Touchscreen to run the machine, will show the working errors and solutions
  4. No boxes, machine stop
  5. All electronic and pneumatic component brands used in the construction of this machine are highest quality name brands globally known in the industry manufactured in countries such as USA, Japan, Germany and France.
  6. Rugged constructed to guarantee a long service life. Most of the body is built with stainless steel 304 and food grade stainless steel (SS304) is used for all parts in contact with products.
  7. Machine is very easy to use and maintain.
Standard Functions
  1. Automatic Sort the filled and sealed capsules
  2. Auto arrange 5*2 capsules and feed into empty boxes
  3. Open the boxes
  4. Fold the bottom of boxes
  5. Fill the capsules into the boxes
  6. Close the top of the boxes
  7. Output the finished capsules
Optional Functions
  1. Print the production date and lot on the boxes
  2. Use Hot glue to close the boxes
Model AF-B10
Suit for box size L（110-160）*W（60-90）*H（15-35）
Box paper material ≥300 g/m2   Foldable boxes
Output height 800-850 mm
Machine speed 15-70 boxes per min
Voltage 380V/50HZ/3PH can be customized as per your local power
Machine size L1700×W1120×H1600mm
Machine weight 1000KGS
Note This is a custom-build machine, so each machine specifications will have different


    Please prove you are human by selecting the heart.

    Samples

    FAQs

    How long need to build one machine like this?

    Normally we need 2-3 months to produce a machine.

    What should I prepare to build a machine?

    As to our experiences, we suggest you ship us your empty containers, sealing materials, and filling materials, This will be a great help for the machine testing.

    What do I need in my factory to work with this machine?

    You only need the big enough air compressor and Nitrogen generator. If you don’t have, we can also offer.

    What's the warranty of this machine?

    We offer 2 years warranty on all our machines, and lifelong maintain service.

    How to install this machine when we get it?

    Machines will ship in a complete package, you will no need to assemble again in your factory. We suggest you to invite our engineers to your factory to train your people.
